Automatic switch 2P 6A curve-C 6kA Hager

Brand: HAGER

Reference: MUN206A

Offer: £18.93
PVP: £90.52
£18.93
  • Quantity
  • In stock. Immediate shipment.
    Taxes included


Description

Hager MU series magneto-thermal automatic switch, 2P, 6A, curve C, breaking capacity 6000A according to UNE EN 60898-1. AENOR certificate.


Features

Number of modules:
2

Details

More information
Characteristics of the 2P 6A C-curve 6kA circuit breaker:
- Number of protected poles: 2
- Number of poles: 2 P
- Type of poles: 2 P
- Curve: C
- With neutral cut-off: No
- Number of modules: 2
- Alignment of the upper terminals for modular devices: Aligned terminals
- Alignment of the lower terminals for modular devices: Aligned terminals
- Rated breaking capacity: 6 kA
- Rated AC operating voltage: 400 V
- Type of supply voltage: AC
- Rated frequency: 50/60 Hz
- Rated voltage of insulation: 500 V
- Rated impulse withstand voltage: 4000 V
- Rated rated current: 6 A
- Service breaking capacity according to EN60898: 6 kA
- Min/max operating value of the thermal relay in AC: 1.13 / 1.45 In
- Min/max threshold value of magnetic relay in AC: 5 / 10 In
- Min/max threshold value of operation of the thermal relay in DC: 7 / 15 In
- Value of the min/max operating level of the thermal relay in DC: 1.13 / 1.45 In
- Breaking capacity 1 pole 400V (EN60947-2): 3 kA
- Assigned breaking power: 6 kA
- Last cutting power in a.c. 400V (EN 60947-2): 10 kA
- Ultimate cutting power in a.c. 415V (EN 60947-2): 10 kA
- Depth of installed product: 70 mm
- Height of installed product: 83 mm
- Width of installed product: 35 mm
- Frequency: 50 at 60 Hz
- Total power dissipated under nominal current conditions: 2.5 W
- Power dissipated per pole: 1.3 W
- Electrical endurance in number of cycles: 4000
- Mechanical endurance in number of maneuvers: 20000
- Type of upper connection for modular devices: Terminal with screws
- Tightening torque: 2.8 Nm
- Type of lower connection for modular devices: Double connection terminal
- Sec .conex. born. His p. and info. rigid cable: 1 / 35 mm²
- Screw terminal terminal connection section: 1 / 25 mm²
- IP protection index: IP20
- Operating temperature: -25…70 °C
- Altitude: 2000 m

* All the information in the technical sheet
